MND-I-6 Marine Navigational Display

Description

MND-I6 offers a comprehensive solution for marine navigation display requirements. It combines the latest GPS and Glonass technology and advanced processing software with an elegant design.Taking the advantage of the standard structure, MND-I 6 is fully integrated to different marine navigation systems and sensors such as wind sensor, gyro-compass, speed log, auto-pilot FCS and radar.    FEATURES ●         Built- in precise GPS and Glonass to monitor navigation data such as time, latitude, longitude, speed, SOG, COG, and heading●         NMEA 0183 compliant●         Graphical presentation of the quality of received signals, position and status of the locked satellites●         Easy calibrating of speed log sensor through software●         Configurable interfaces and ports for defining different inputs and outputs●         Fully integrated and PC-based design●         Customized interfaces to meet the user requirements●         Easy define and labelling new routes and waypoints●         Fully adjustments to zero-dim for night vision●         Bright, sunlight and wide-viewing LCD●         Optional DGPS to increase the accuracy●         Rugged and waterproof design●         Easy-to-use software controlled through soft-touch buttons●         Moving map application taking the advantages of the preloaded worldwide satellite map●         Switch to dead reckoning in case of poor GPS signal quality
